ESP HDVIEW IP White 2.8mm Lens 5MP 1920p Resolution IP Camera | HDVIPC28FDW

ESP HDVIEW IP White 2.8mm Lens 5MP 1920p Resolution IP Camera | HDVIPC28FDW

Name: ESP HDVIEW IP White 2.8mm Lens 5MP 1920p Resolution IP Camera | HDVIPC28FDW
Brand: ESP HDView IP CCTV
SKU: HDVIPC28FDW
Price: 106.97 GBP
Availability: InStock
Rating: 5 (1 reviews)

SKU: HDVIPC28FDW

The ESP HDVIEW IP White 2.8mm Lens 5MP 1920p Resolution IP Camera is a POE (Power-Over-Ethernet) unit which enables the camera and power feed to be wired in Cat5e cable up to 100 meters and making installations more convenient.

Details

ESP HDVIEW IP White 2.8mm Lens 5MP 1920p Resolution IP Camera | HDVIPC28FDW

The Camera is HD 5MP 1920p resolution viewing with 10m Infrared LED Illumination and 92° Viewing Angle.

Features

HD 5MP Resolution
2.8mm Fixed Lens
1/2.7" Image Sensor
10m Infrared LED Illumination
92° Viewing Angle
H265 Compression
ONVIF Compliant
Additional Features: SD storage / Microphone
IP66 Housing Ingress Protection

Technical Specifications

Sensor Size	1/2.7"
Lens	2.8mm
Effective Pixels	5MP (2592 X 1944)
Ingress Protection	IP66
Minimum Illumination	0.05 Lux
Auto Electronic Shutter	1/5 ~ 1/20000s
IR Distance	10 Meters
Compression	H.265/H.264
Video bit rate	256Kbps ~ 8Mbps
Interface	RJ45 10M / 100M Ethernet
Network Functions	TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
Network Monitoring	Web browser, Client Software, Android & IOS
Storage	microSD Card (<128G Capcity)
Audio	Mic.
Power	12vDC/POE
Consumption	? 7W
Dimension	Ø120X64mm
Weight	450g
Storage Temperature	-30°C+60°C
Operating Temperature	-30°C+55°C

Reviews

Downloads

Title
ESP HDVIEW 2.8mm Lens 5MP IP Camera Data Sheet
