Optimum Digital Immersion and General Purpose Timeswitch OP-IHTDIGI

Optimum Digital Immersion and General Purpose Timeswitch OP-IHTDIGI

The Optimum Digital Immersion and General Purpose Timeswitch is suitable for surface mounting with single channel 16 Amps and day group programming is Mon – Sun; Mon – Sat; Mon – Fri; Sat – Sun or any individual day.  All programme spaces can be set for any time / day combination, and either ON or OFF functions. If all spaces are used for seven day switching operations.

Features

• AC switching capacity: - resistive load 16A 250v AC, inductive load cos ∅ 0.6 4A 250v AC
• Not suitable for discharge lighting
• Minimum switching current 100mA (20v) AC/DC
• Contact type - volt free SPDT changeover
• Ambient temperature -100C to +550C
• Accuracy typically ± 2.5 sec. / day @ 200C
• Battery back up - 3 years @ 200C
• Minimum switching time one minute
• Manual override - advance ON/OFF (advance is self resetting)
