Click GridPro 20AX Double Pole Keyswitch Module 'Emergency Test' Black Nickel, Black Insert | GM2046BKBNET

Click GridPro GM2046BKBNET: an 'Emergency Test' marked 20AX double pole keyswitch module in black nickel with a black insert. It lets an authorised person take emergency lighting off supply for its periodic test, then restore normal operation with the key.

Every GridPro module clips into or screws into a GridPro frontplate, so plates and modules can be mixed to suit the job. Browse the full range of Click GridPro plates and modules to build the plate around this module.

Choose black nickel for a dark metallic look for contemporary interiors, set against a black insert. Terminals accept 3 x 2.5mm² or 2 x 4mm² conductors, and the module fixes with either a clip-on or screw-in action. Plan for a minimum 25mm back box, rising to 35mm with a flat plate.

Key features

• Key operated double pole switching that stops unauthorised use
• 20AX rating, suitable for inductive loads
• Marked 'Emergency Test' for emergency lighting test circuits
• Black Nickel finish with black insert
• 'Clip-on' and 'screw-in' fitting
• Matches existing Click wiring accessories

• Range: Click GridPro
• Manufacturer part number: GM2046BKBNET
• Rating: 20AX, 250V AC
• Function: Double pole key operated switching
• Legend: Emergency Test
• Terminal capacity: 3 x 2.5mm² or 2 x 4mm²
• Minimum back box depth: 25mm (35mm with a flat plate)
• Module size: 24.5mm (W) x 50mm (H)
• Standard: BS EN 60669-1
• Switch finish: Black Nickel
• Insert colour: Black
• Operating temperature: -5°C to +40°C

Suitable for

Emergency lighting circuits in offices, schools, shops and public buildings that need a key controlled test facility. Note that black nickel is offered with a black insert only.
