Click GridPro 20AX Double Pole Keyswitch Module 'Emergency Test' Polished Chrome, Black Insert | GM2046BKCHET
SKU: GM2046BKCHET
Brand: Click Grid Pro
20AX Double Pole Keyswitch Module marked 'Emergency Test', finished in polished chrome with a black insert. Clips or screws into any Click GridPro frontplate and matches existing Click accessories. Part number GM2046BKCHET.
Click GridPro GM2046BKCHET: an 'Emergency Test' marked 20AX double pole keyswitch module in polished chrome with a black insert. It lets an authorised person take emergency lighting off supply for its periodic test, then restore normal operation with the key.
GridPro is Click Scolmore's interchangeable plate and module system, styled to match existing Click wiring accessories. Browse the full range of Click GridPro plates and modules to build the plate around this module.
The polished chrome rocker gives a mirror bright chrome look, so pair it with a GridPro frontplate in a matching or complementary finish. Terminals accept 3 x 2.5mm² or 2 x 4mm² conductors, and the module fixes with either a clip-on or screw-in action. Plan for a minimum 25mm back box, rising to 35mm with a flat plate.
Key features
- Key operated double pole switching that stops unauthorised use
- Marked 'Emergency Test' for emergency lighting test circuits
- 20AX rating, suitable for inductive loads
- Polished Chrome finish with black insert
- 'Clip-on' and 'screw-in' fitting
- Matches existing Click wiring accessories
- Range: Click GridPro
- Manufacturer part number: GM2046BKCHET
- Rating: 20AX, 250V AC
- Function: Double pole key operated switching
- Legend: Emergency Test
- Terminal capacity: 3 x 2.5mm² or 2 x 4mm²
- Minimum back box depth: 25mm (35mm with a flat plate)
- Module size: 24.5mm (W) x 50mm (H)
- Standard: BS EN 60669-1
- Switch finish: Polished Chrome
- Insert colour: Black
- Operating temperature: -5°C to +40°C
Suitable for
Emergency lighting circuits in offices, schools, shops and public buildings that need a key controlled test facility.
