Click GridPro 20AX Double Pole Keyswitch Module 'Emergency Test' Black Insert | GM2046BKET
SKU: GM2046BKET
Brand: Click Grid Pro
Click GridPro double pole keyswitch module marked 'Emergency Test', rated 20AX for inductive loads and finished in black. Fits every GridPro grid plate. Part number GM2046BKET. Plates and yokes are sold separately.
Marked 'Emergency Test', the Click GridPro GM2046BKET keyswitch module gives 20AX double pole switching in black. It lets an authorised person take emergency lighting off supply for its periodic test, then restore normal operation with the key.
Every GridPro module clips into or screws into a GridPro frontplate, so plates and modules can be mixed to suit the job. See all Click GridPro plates and modules for frontplates, yokes and companion modules.
The black moulded finish sits cleanly in plain black grid plates. Wire it with up to 3 x 2.5mm² or 2 x 4mm² conductors, then clip or screw it into place. A 25mm back box is the minimum, or 35mm if a flat plate is fitted.
Key features
- Key operated double pole switching that stops unauthorised use
- 20AX rating, suitable for inductive loads
- Marked 'Emergency Test' for emergency lighting test circuits
- Black insert
- 'Clip-on' and 'screw-in' fitting
- Matches existing Click wiring accessories
- Range: Click GridPro
- Manufacturer part number: GM2046BKET
- Rating: 20AX, 250V AC
- Function: Double pole key operated switching
- Legend: Emergency Test
- Terminal capacity: 3 x 2.5mm² or 2 x 4mm²
- Minimum back box depth: 25mm (35mm with a flat plate)
- Module size: 24.5mm (W) x 50mm (H)
- Standard: BS EN 60669-1
- Insert colour: Black
- Operating temperature: -5°C to +40°C
Suitable for
Emergency lighting circuits in offices, schools, shops and public buildings that need a key controlled test facility.
