Click GridPro 20AX DP Keyswitch Module 'Emergency Test' Polished Brass, Polar White Insert | GM2046PWBRET
SKU: GM2046PWBRET
Brand: Click Grid Pro
A 20AX double pole key operated GridPro switch module marked 'Emergency Test' in polished brass with a polar white insert. Fits all GridPro plates and suits inductive loads. Part number GM2046PWBRET. Plates and yokes are sold separately.
Click GridPro GM2046PWBRET: an 'Emergency Test' marked 20AX double pole keyswitch module in polished brass with a polar white insert. It lets an authorised person take emergency lighting off supply for its periodic test, then restore normal operation with the key.
Every GridPro module clips into or screws into a GridPro frontplate, so plates and modules can be mixed to suit the job. Pair it with a frontplate from our Click GridPro plates and modules range to complete the installation.
In polished brass, the module brings a bright, reflective brass look to the grid; choose the frontplate to suit the room. Fitting is straightforward: the module clips into the yoke or screws in, and its terminals take 3 x 2.5mm² or 2 x 4mm² conductors. Allow a back box of at least 25mm, or 35mm where a flat plate is used.
Key features
- Key operated double pole switching that stops unauthorised use
- 20AX rating, suitable for inductive loads
- Marked 'Emergency Test' for emergency lighting test circuits
- Polished Brass finish with polar white insert
- 'Clip-on' and 'screw-in' fitting
- Matches existing Click wiring accessories
- Range: Click GridPro
- Manufacturer part number: GM2046PWBRET
- Rating: 20AX, 250V AC
- Function: Double pole key operated switching
- Legend: Emergency Test
- Terminal capacity: 3 x 2.5mm² or 2 x 4mm²
- Minimum back box depth: 25mm (35mm with a flat plate)
- Module size: 24.5mm (W) x 50mm (H)
- Standard: BS EN 60669-1
- Switch finish: Polished Brass
- Insert colour: Polar White
- Operating temperature: -5°C to +40°C
Suitable for
Emergency lighting circuits in offices, schools, shops and public buildings that need a key controlled test facility.
