Click GridPro 20AX Double Pole Switch Module 'Oven' Satin Chrome, Polar White Insert | GM2018PWSC-OV
SKU: GM2018PWSC-OV
Brand: Click Grid Pro
20AX Double Pole Switch Module marked 'Oven', finished in satin chrome with a polar white insert. Clips or screws into any Click GridPro frontplate and matches existing Click accessories. Part number GM2018PWSC-OV.
Click GridPro GM2018PWSC-OV: a 20AX module marked 'Oven' in satin chrome with a polar white insert, giving double pole switching that isolates both live and neutral. Clear marking matters on a bank of appliance isolators: the 'Oven' legend shows at a glance which switch serves the oven.
The GridPro range pairs a wide choice of plate finishes with modules in matching insert colours. See all Click GridPro plates and modules for frontplates, yokes and companion modules.
Choose satin chrome for a soft, low sheen chrome look, set against a polar white insert. Wire it with up to 3 x 2.5mm² or 2 x 4mm² conductors, then clip or screw it into place. A 25mm back box is the minimum, or 35mm if a flat plate is fitted.
Key features
- Double pole switching that isolates both live and neutral
- Laser etched 'Oven' legend
- 20AX rating, suitable for inductive loads
- Satin Chrome finish with polar white insert
- 'Clip-on' and 'screw-in' fitting
- Matches existing Click wiring accessories
- Range: Click GridPro
- Manufacturer part number: GM2018PWSC-OV
- Rating: 20AX, 250V AC
- Function: Double pole switching
- Legend: Oven
- Terminal capacity: 3 x 2.5mm² or 2 x 4mm²
- Minimum back box depth: 25mm (35mm with a flat plate)
- Module size: 24.5mm (W) x 50mm (H)
- Standard: BS EN 60669-1
- Switch finish: Satin Chrome
- Insert colour: Polar White
- Operating temperature: -5°C to +40°C
Suitable for
Kitchens and utility rooms where the oven needs its own clearly marked isolator, in homes, rentals and fit outs.
