Click GridPro 20AX Double Pole Switch Module 'Tumble Dryer' Satin Chrome, Polar White Insert | GM2018PWSC-TD
SKU: GM2018PWSC-TD
Brand: Click Grid Pro
A 20AX double pole GridPro switch module marked 'Tumble Dryer' in satin chrome with a polar white insert. Fits all GridPro plates and suits inductive loads. Part number GM2018PWSC-TD. Plates and yokes are sold separately.
Laser etched 'Tumble Dryer', the Click GridPro GM2018PWSC-TD gives double pole switching that isolates both live and neutral for the tumble dryer circuit, in satin chrome with a polar white insert. The etched legend tells anyone at the board which appliance the switch controls, so the tumble dryer can be isolated without guesswork.
The GridPro range pairs a wide choice of plate finishes with modules in matching insert colours. See all Click GridPro plates and modules for frontplates, yokes and companion modules.
In satin chrome, the module brings a soft, low sheen chrome look to the grid; choose the frontplate to suit the room. Terminals accept 3 x 2.5mm² or 2 x 4mm² conductors, and the module fixes with either a clip-on or screw-in action. Plan for a minimum 25mm back box, rising to 35mm with a flat plate.
Key features
- Double pole switching that isolates both live and neutral
- 20AX rating, suitable for inductive loads
- Laser etched 'Tumble Dryer' legend
- Satin Chrome finish with polar white insert
- 'Clip-on' and 'screw-in' fitting
- Matches existing Click wiring accessories
- Range: Click GridPro
- Manufacturer part number: GM2018PWSC-TD
- Rating: 20AX, 250V AC
- Function: Double pole switching
- Legend: Tumble Dryer
- Terminal capacity: 3 x 2.5mm² or 2 x 4mm²
- Minimum back box depth: 25mm (35mm with a flat plate)
- Module size: 24.5mm (W) x 50mm (H)
- Standard: BS EN 60669-1
- Switch finish: Satin Chrome
- Insert colour: Polar White
- Operating temperature: -5°C to +40°C
Suitable for
Kitchens and utility rooms where the tumble dryer needs its own clearly marked isolator, in homes, rentals and fit outs.
