BG Evolve Matt Blue Intelligent Trailing Edge Single Secondary Touch Dimmer Switch | PCDDBTDS1B
SKU: PCDDBTDS1B
Evolve Intelligent trailing edge dimmers have a lower minimum load than leading edge dimmers, offering greater compatibility for LED, Halogen, CFL and incandescent lamps.
BG Evolve Matt Blue Intelligent Trailing Edge Single Secondary Touch Dimmer Switch | PCDDBTDS1B
Evolve Intelligent trailing edge dimmers have a lower minimum load than leading edge dimmers, offering greater compatibility for LED, Halogen, CFL and incandescent lamps. The soft start brings the lights to a set level in around 1 second and extends the life of lamps
Overload protection prevents failure if you mistakenly connect your dimmer to too many lights or transformers, and will turn the lights down or off until the load is corrected
Designed with a slim, screwless profile, this comprehensive range offers a complete solution for any domestic or commercial application.
Features
- Intelligent trailing edge dimmers have a lower minimum load than leading edge dimmers, offering greater compatibility for LED, Halogen, CFL and incandescent lamps
- Soft start brings the lights to a set level in around 1 second and extends the life of lamps
- Overload protection prevents failure if you mistakenly connect your dimmer to too many lights or transformers, and will turn the lights down or off until the load is corrected
- Smooth dimming control
- Silent operation - no noise when dimming
- Support for lower wattage lamps eliminates flicker
- Touch dimmer control
- Captive backed out terminal screws prevent screw loss
- Manufactured to BS EN 60669-2-1
- 3 x 1mm² 2 x 1.5mm² & 1 x 2.5mm²
- Minimum mounting box depth – 25mm
Load Rating (Max/Min per module)
- Dimmable LED 5-100W
- Tungsten/Incandescent 5-200W
- Halogen 20-200W
- Dimmable Compact Fluorescent (CFL) 5-100W
Installation Note
- Master can only be used in a one way switching circuit where one switch controls a light (or circuit) i.e. on or off.
- For two way switching, where a light (or circuit) is controlled by two switches, the master touch dimmer must be used with a secondary touch dimmer at the secondary location.
- A master touch dimmer cannot be used in combination with a traditional light switch or any other dimmer switch.
