Takex 200m External / 400m Internal Single Channel Quad Beam Detector PB-200F
SKU: PB-200F
Takex
The Takex 200m External / 400m Internal Single Channel Quad Beam Detector is the professional choice in outdoor protection. Choose from the best alarm sensors we have to offer
£255.61 (inc. VAT)£213.01 (exc. VAT)
Secure shopping guaranteed
Free Delivery on orders over £100
Takex 200m External / 400m Internal Single Channel Quad Beam Detector PB-200F
The Takex 200m External / 400m Internal Single Channel Quad Beam Detector is the professional choice in outdoor protection. The Takex Quad beam detectors synchronise 16 beam paths for maximum stability in severe weather conditions, perfect for long range perimeter protection.
For distances up to 200m (660ft) outdoor / 400m (1320ft) indoor.
Features
- Synchronised Quad Beams for maximum stability in severe weather conditions
- Double Modulated beam for unsurpassed immunity to direct and reflected sunlight, vehicle headlights and other light sources.
- Built-in view finder and monitor jack output for easy beam alignment
- 180 degree rotating optics for increased installation flexibility
- Automatic Gain Control circuit
| brand | Takex | colour | Black |
| colour | Black | ||
| Product type | Photoelectric Beam Sensor | Detection system | Simultaneous breaking of 4 beams |
| Detection system | Simultaneous breaking of 4 beams | ||
| Infrared beam | LED pulsed beam, Double modulation | Protection distance | Outdoor 200m (660ft) or lessIndoor 400m (1320ft) or less |
| Protection distance | Outdoor 200m (660ft) or lessIndoor 400m (1320ft) or less | ||
| Max. beam range | Outdoor 2000m (6600ft) or lessIndoor 2000m (6600ft) or less | Response time | 50msec. |
| Response time | 50msec. | ||
| Supply voltage | 12V to 30VDC (Non-polarity) | Current consumption | 75mA or less |
| Current consumption | 75mA or less | ||
| Alarm output | Dry contact relay output form CContact action : Interruption time + delay timeContact capacity : 30V AC/DC, 0.5A or less | Tamper output | Dry contact relay 1b (N/C)Action : Activated when cover is detachedContact capacity : 30V AC/DC, 0.5A or less |
| Tamper output | Dry contact relay 1b (N/C)Action : Activated when cover is detachedContact capacity : 30V AC/DC, 0.5A or less | ||
| Alarm LED | Red LED (Receiver)ON : when an alarm is initiated. | Attenuation LED | Red LED (Receiver)ON : when beam is attenuated. |
| Attenuation LED | Red LED (Receiver)ON : when beam is attenuated. | ||
| Functions | Sound check : Audible check of beam levelMonitor jack outputFrost proof cover | Ambient temperature range | -25°C to +55°C (-13°F to +131°F) |
| Ambient temperature range | -25°C to +55°C (-13°F to +131°F) | ||
| Mounting positions | Outdoor (Perimeter protection) | Wiring | Terminals |
| Wiring | Terminals | ||
| Weight | Transmitter : 1.3Kg (45.5oz)Receiver : 1.3Kg (45.5oz) | Appearance | PC resin (wine red) |
| Appearance | PC resin (wine red) |
