Texecom Premier Outdoor Pir Detector Black | AFQ-0001

Texecom Premier Outdoor Pir Detector Black | AFQ-0001

The Premier External TD is a purpose built outdoor sensor for security applications. Utilising two non-overlapping PIR sensors with superior mirrored optics, the Prestige External TD is designed to perform in harsh outdoor environments.

Features

• 12m volumetric range, adjustable to 8, 5 & 2 metres
• No disassembly required for installation
• 90° viewing angle - rotatable through 180°
• Environmentally sealed IP65 enclosure
• Digital temperature compensation for hot climates
• Auxiliary input for wiring multiple detectors
• High white light immunity
• Day/night mode

Specifications

• Current Consumption: 28mA
• Detection Method: Dual, non-overlapping, digital PIR
• Alarm Output: NC/NO selectable relay. Rated 50V DC, 100mA, 18Ω
• Tamper Detection: Wall and case. Sealed non-mechanical switch.
• Tamper Output: NC relay. Rated 50V
• Operating Temperature: -35˚C (-31˚F) to +55˚C (+131˚C) DC, 100mA, 18Ω
• Dimensions: 250mm x 86.5mm x 87mm
• Packed Weight: 550g (20 oz) approx
• Mounting Height: 1.0 - 1.4m, 1.2m nominal
• Supply Voltage: 9-16 VDC

**Texecom products are only available for purchase within the United Kingdom and Republic Of Ireland.**
