Name: Xpelair XIMX100 100mm Centrifugal Inline Fan 93078AW
Brand: Xpelair
SKU: XIMX100
Price: 65.76 GBP
Availability: InStock
Rating: 5 (1 reviews)

Xpelair

Alert Electrical

Silent Extractor Fans

Inline Extractor Fans

all-products

Brands-X

Powerful Extractor Fans

Xpelair XIMX100 100mm Centrifugal Inline Fan 93078AW The Xpelair XIMX100 100mm Centrifugal Inline Fan offers duties for a wide range of ducted applications. The unit come complete with a convenient mounting cradle which makes installation or subsequent inspection simple. The terminal box is easily accessible, simplifying the electrical connection. Features Two speed Supplied with convenient installation mounting cradle Lubricated for life, maintenance free motors with thermal cut-out protection IPX4 rated Extraction Rate 145 / 187m³/hr Noise Level 27 / 36dBA at 3m In-Line Mounted Loft / Ceiling 2 Year Manufacturer's Guarantee (T&Cs Apply) Specification Extract performance (FID, M³/h) Max/Min 145 / 187 Extract performance (FID, l/s) Max/Min 40 / 52 Sound pressure level db(A)@3m 27 / 36 Operation Speeds 2 UK Guarantee (Years) 2 IPX Rating 4

<h2>Xpelair XIMX100 100mm Centrifugal Inline Fan 93078AW</h2>  <p>The Xpelair XIMX100 100mm Centrifugal Inline Fan offers duties for a wide range of ducted applications. The unit come complete with a convenient mounting cradle which makes installation or subsequent inspection simple. The terminal box is easily accessible, simplifying the electrical connection.</p>  <h2>Features</h2>  <ul>  <li>Two speed</li>  <li>Supplied with convenient installation mounting cradle</li>  <li>Lubricated for life, maintenance free motors with thermal cut-out protection</li>  <li>IPX4 rated</li>  <li>Extraction Rate 145 / 187m³/hr</li>  <li>Noise Level 27 / 36dBA at 3m</li>  <li>In-Line Mounted Loft / Ceiling</li>  <li>2 Year Manufacturer's Guarantee (T&amp;Cs Apply)</li>  </ul>  <h2>Specification</h2>  <table style="width: 448px; height: 129px;" border="2">  <tbody>  <tr>  <td><strong>Extract performance (FID, M³/h) Max/Min</strong></td>  <td>145 / 187</td>  </tr>  <tr>  <td><strong>Extract performance (FID, l/s) Max/Min</strong></td>  <td>40 / 52</td>  </tr>  <tr>  <td><strong>Sound pressure level db(A)@3m</strong></td>  <td>27 / 36</td>  </tr>  <tr>  <td><strong>Operation Speeds</strong></td>  <td>2</td>  </tr>  <tr>  <td><strong>UK Guarantee (Years)</strong></td>  <td>2</td>  </tr>  <tr>  <td><strong>IPX Rating</strong></td>  <td>4</td>  </tr>  </tbody>  </table>
