Click GridPro 20AX Double Pole Keyswitch Module 'Emergency Test' Satin Brass, Black Insert | GM2046BKSBET
SKU: GM2046BKSBET
Brand: Click Grid Pro
Click GridPro double pole keyswitch module marked 'Emergency Test', rated 20AX for inductive loads and finished in satin brass with a black insert. Fits every GridPro grid plate. Part number GM2046BKSBET.
The Click GridPro GM2046BKSBET is a 20AX double pole keyswitch module marked 'Emergency Test', finished in satin brass with a black insert. It lets an authorised person take emergency lighting off supply for its periodic test, then restore normal operation with the key.
GridPro is Click Scolmore's interchangeable plate and module system, styled to match existing Click wiring accessories. Browse the full range of Click GridPro plates and modules to build the plate around this module.
The satin brass rocker gives a muted brushed brass tone, so pair it with a GridPro frontplate in a matching or complementary finish. Terminals accept 3 x 2.5mm² or 2 x 4mm² conductors, and the module fixes with either a clip-on or screw-in action. Plan for a minimum 25mm back box, rising to 35mm with a flat plate.
Key features
- Key operated double pole switching that stops unauthorised use
- 20AX rating, suitable for inductive loads
- Marked 'Emergency Test' for emergency lighting test circuits
- Satin Brass finish with black insert
- 'Clip-on' and 'screw-in' fitting
- Matches existing Click wiring accessories
- Range: Click GridPro
- Manufacturer part number: GM2046BKSBET
- Rating: 20AX, 250V AC
- Function: Double pole key operated switching
- Legend: Emergency Test
- Terminal capacity: 3 x 2.5mm² or 2 x 4mm²
- Minimum back box depth: 25mm (35mm with a flat plate)
- Module size: 24.5mm (W) x 50mm (H)
- Standard: BS EN 60669-1
- Switch finish: Satin Brass
- Insert colour: Black
- Operating temperature: -5°C to +40°C
Suitable for
Emergency lighting circuits in offices, schools, shops and public buildings that need a key controlled test facility.
