FireAngel Mains Powered Heat Alarm HM-SN-1
The FireAngel Mains Powered Heat Alarm Thermistek heat alarm has a patented heat dish to target radiated heat directly onto the heat sensor for a faster reaction to potential fire risk.
FireAngel Mains Powered Heat Alarm HM-SN-1
The FireAngel Mains Powered Heat Alarm Thermistek heat alarm has a patented heat dish to target radiated heat directly onto the heat sensor for a faster reaction to potential fire risk. The Thermistek heat alarm, provides Class A1 heat detection and has a sealed for life tamper proof battery that significantly reduces energy consumption.
All FireAngel Heat alarms are easy to fit with a low profile mounting base and aesthetic design to complement any modern interior.
Normal smoke alarms are unsuitable for use in kitchens due to the amount of false alarms activations from the likes of burnt toast.
Features
- Thermistek heat alarm, provides Class A1 heat detection with patented heat dish to provide faster reaction to heat in the kitchen
- Sealed for life tamper proof battery back-up.
- Low energy usage – typically less than 10% of the average AC heat alarm.
- Ultra slim, integrated mounting base. Quick and simple installation reduces time on site.
- Combined central test / silence / locate button.
- Mixed system compatibility:
- Wireless and hardwired.
- Mains and battery powered alarms.
- Low profile design, aesthetically pleasing that complements all modern interiors.
Specification
| Product Type | Heat Alarm |
| Supply Voltage | 230V AC, 50Hz |
| Dimensions | 141.5mm x 43mm |
| Battery Backup | 10 year sealed for life lithium battery |
| Technology | Thermistek |
| Alarm Sound Level | 85dB (A) at 3m (minimum) |
| Installation Positions | Ceiling, Wall |
| Alarms at Temperature Range | 54°C to 62°C |
| Operating Temperature | +4°C to +38°C |
| Operating Humidity | Up to 90% RH non-condensing |
| Storage Humidity | Up to 93% RH non-condensing |
| Storage Temperature | -20°C to +60°C |
| Plastic Material | ABS – UL94 V0 flame retardant |
| Warranty | 5 years |
| Certified to | BS 5446-2: 2003 |
| Weight | 284g |
| Independently tested to | ETSI EN 300 220-2 V2.3.2 (2010-02) EN300489-1 &-3 EN300220-2 – Radio |
| Maximum Number of Connected Units | 30 Hardwired |
| Operating Frequency | 868 MHz |
| Installation Area | Hallway, Kitchen, Landing, Living Room |
| Dimensions | Diameter: 141.5mm, Height: 53mm, Weight 264g |
